What is a Modular container house?
Take the container as an example, (common size is 6m long, 3m wide, 2.9m high) as the basic unit, through welding, bolt connection or assembly technology to achieve rapid combination, assembled into one house, saving time and effort.
Prefab cargo container homes are a kind of galvanized steel container, with galvanized steel as the main material, corrosion resistance. The sandwich panel is iron sheet on both sides and foam board in the middle. It adopts the space combination of standard modulus series and the components are bolted to form an environmentally friendly and economical movable board house.
Jiangsu Longze has 20 years of professional container manufacturing experience. Our Modular container house complies with international 9001 and CE certification.
Custom Colors
A. We can change the color of the wall panels to blue, white or gray according to customer requirements.
B. Doors and roof tiles are usually white. The standard floor color is gray, but you can choose a different floor color, such as wood grain color, etc.
Wall Panel Color
Floor Color Options
Specifications
Technical Specifications |
||||
|
Component Name (Customizable) 6055*2990*2896mm |
This Configuration is the Standard Model |
Unit |
Quantity |
|
|
Main Frame 2.3mm |
Top Frame |
Electrostatic painted top crossbeam 170mm |
pc |
2.00 |
|
Electrostatic painted top side beam 170mm |
pc |
2.00 |
||
|
40*60 1.3mm square tube |
pc |
5.00 |
||
|
20*40mm square tube, 20*20mm square tube |
pc |
3.00 |
||
|
Bottom Frame |
Electrostatic painted bottom crossbeam 160mm |
pc |
2.00 |
|
|
Electrostatic painted bottom side beam 160mm |
pc |
2.00 |
||
|
Square tube 50*100 horizontal brace |
pc |
9.00 |
||
|
Integrated flashing channel |
set |
1.00 |
||
|
Columns |
Fully painted columns, 150*210mm |
pc |
4.00 |
|
|
Corner Fittings |
Painted upper corner fitting 160*160*200mm |
pc |
4.00 |
|
|
Painted lower corner fitting 160*160*160mm |
pc |
4.00 |
||
|
Roofing Sheet |
0.46mm color steel coil, pressed into special 980-wave type for higher strength, no deformation, no water pooling, 360°咬合, special waterproofing method |
set |
1.00 |
|
|
Roof Insulation |
50mm glass wool insulation, density 18kg/m³, PE resin moisture-proof film |
set |
1.00 |
|
|
Downpipe |
Downpipe |
50# PVC downpipe |
pc |
4.00 |
|
Ceiling |
Complete ceiling |
2820*831*0.3mm color steel integrated patterned ceiling panel with aluminum corner |
set |
1.00 |
|
Door |
Steel security door |
Prefabricated container luxury steel integrated door 840*2035 |
pc |
1.00 |
|
Window |
Security window |
Double-glazed insulated PVC window 925*1100mm, standard with security and screen |
pc |
2.00 |
|
Wall Panel |
Composite panel |
950*50mm rock wool composite panel, double-sided 0.3mm steel plate, rock wool density 70kg/m³³ |
set |
1.00 |
|
Floor |
Cement fiber pressure board |
2830*1174*18mm |
set |
1.00 |
|
Floor vinyl |
1.6mm |
set |
1.00 |
|
|
Baseboard |
PVC material |
set |
1.00 |
|
|
Corner bead |
Internal Corner Bead |
Color steel corner bead, white/gray |
pc |
4.00 |
|
Electrical Components |
Electrical Components |
Industrial socket box, industrial socket (1 set), distribution box (1 pc), 32A circuit breaker (1 pc), three 10A duplex outlets, single switch (1 pc), 16A triple outlet (1 pc), 2 LED strip lights, full wiring set |
set |
1.00 |
|
Auxiliary Materials |
Auxiliary Materials |
Screws, self-drilling screws, sealant, internal container connectors |
set |
1.00 |
Advantages and features of modular container houses
1. Flexible and reusable
Convenient transportation: Modular design supports overall or split transportation, adapting to remote areas or complex terrain.
Detachable migration: The house can be quickly disassembled and reassembled to meet temporary housing needs or site change requirements.
2. Excellent environmental performance: There is no dust pollution during the installation process.
4. Customized design support, we customize the size, color, and interior layout of the guest team according to your needs
5. The service life is 15 to 20 years
Application
1. It can be used as office, residence, and dormitory
Specifications: Specifications of the products on sale
Size:6055*2990*2896 can be customized
