Introduction
20 years of professional container manufacturing experience, obtained international 9001, and CE certification, as well as a number of container invention patents, crate modular houses are prefabricated building forms based on standardized box units, integrating industrial design and rapid construction technology, suitable for multi-scene space needs, more reasonable design, each room is decorated according to standards, and all living facilities can be assembled.
Details
Jiangsu Suqian Longze Modular Building Co., Ltd. was established in 2021 with a registered capital of 30 million yuan; it is affiliated to Longwan Group. Jiangsu Suqian Longze Modular Building Co., Ltd. is a professional enterprise in the field of integrated housing integrating scientific research, production, installation and service, mainly engaged in wholesale and retail. The company covers an area of 16,615 square meters, with an existing plant area of more than 9,000 square meters and 28 employees. It mainly produces various types of sandwich panels and various types of containers. There are two rock wool sandwich panel production lines, one electrostatic spraying line, five welding production lines, one shearing machine, one bending machine, three color corrugated tile production lines, and four steel forming production lines. After the implementation of the production, it can produce 200,000 meters of various sandwich panels and 10,000 containers of various types per year. It can produce 100 fast-assembly boxes, 30 packing boxes, 45 fixed boxes, and 3,000 meters of sandwich panels per day.
Frame
A. We use hot-dip galvanized Q235 steel for all beams, columns and link keys. It is high-performance and rust-proof. Some factories only use electrolytic plates or black steel materials, which will rust easily. We are rust-free for many years.
B. We use 2.5mm galvanized steel. Other factories only use 2.3mm steel. Our products are stronger. Use longer.
Large Space and Luxury Decoration
A. Large Space: Our standard exterior dimensions are 6055*2990*2896mm. This is much larger than most mobile homes, which are only 2.4x6x 2.5m.
B. Luxury Decoration: The steel structure is hidden inside the wall, the cables are hidden inside the ceiling, and there is iron sheet edging.
High-performance drainage system
A. Our units feature a four-side internal drainage system. The curved pieces with troughs and aqueducts are hidden in the columns, working together to allow water to flow out easily. Even heavy rain will not clog this drainage system. Other plants have smaller drainage channels and the gutters are easily clogged.
B. All our containers are assembled using bolts. No welding is required. This means that the container house is easy to assemble. It is easy for 2 adults to move all the materials and assemble them.
Firm hanging head
We use 3.5mm thick steel as the hanging head. It is very strong and ensures safety when lifting.
1. Iron ceiling
A. We use 0.426mm iron ceiling, which is simple and durable.
Top tile
We use 0.426mm wave top tile. Insert the top tile into the wave of another top tile to prevent roof leaks. The curved roof also makes the water drain faster.
Specification parameters
|
Technical specifications requirements for packaging boxes |
||||
|
Component name (customizable) 6055 * 2990 * 2896mm |
This configuration is a standard model |
Unit |
Quantity |
|
|
Main frame 2.3mm |
Top frame |
Electrostatic baking paint top crossbeam 170mm |
Branch |
2.00 |
|
Electrostatic baking paint top side beam 170mm |
Branch |
2.00 |
||
|
40 * 60 1.3mm square tube |
Branch |
5.00 |
||
|
20 * 40 * mm square tube, 20 * 20 * mm square tube |
Branch |
3.00 |
||
|
Bottom frame |
Electrostatic baking paint bottom crossbeam 160mm |
Branch |
2.00 |
|
|
Electrostatic baking paint bottom side beam 160mm |
Branch |
2.00 |
||
|
Square tube 50 * 100 cross brace |
Branch |
9.00 |
||
|
Integrated floodwater tank |
Cover |
1.00 |
||
|
Column |
Complete set of painted columns, 150 * 210mm |
Branch |
4.00 |
|
|
Corner piece |
Painted corner piece 160 * 160 * 200mm |
Individual |
4.00 |
|
|
Painted corner piece 160 * 160 * 160mm |
Individual |
4.00 |
||
|
Color roll cap |
0.46mm color steel coil, pressed into a special 980 watt shape, with higher strength, no deformation, no water retention, 360 degree bite, special waterproof method |
Cover |
1.00 |
|
|
Top insulation |
50mm insulation glass wool, melting weight 18kg/m ³, PE resin moisture-proof film |
Cover |
1.00 |
|
|
Downpipe |
Downpipe |
50 # PVC downpipe |
Branch |
4.00 |
|
Suspended ceiling |
Complete ceiling |
2820 * 831 * 0.3mm color steel integrated ceiling panel with patterned pattern, with angled aluminum |
Cover |
1.00 |
|
Door |
Steel Security Doors |
Luxury steel integrated door for packaging box 840 * 2035 |
Individual |
1.00 |
|
Window |
Security window |
Double glass hollow plastic steel window 925 * 1100mm, equipped with anti-theft and screen windows as standard |
Individual |
2.00 |
|
Wallboard |
Composite plate |
950 * 50mm rock wool composite board, double-sided 0.3 steel plate, rock wool melting weight 70kg/m ³ |
Cover |
1.00 |
|
Ground |
Cement pressure fiberboard |
2830*1174*18mm |
Cover |
1.00 |
|
Floor leather |
1.6mm, Floor leather |
Cover |
1.00 |
|
|
Baseboard |
PVC material |
Cover |
1.00 |
|
|
Inside corner |
Concave line |
Color steel inner corner line, white gray |
Branch |
4.00 |
|
Electric distribution |
Electric distribution |
Industrial socket box, 1 set of industrial sockets, 1 distribution box, 1 air switch (32A), 3 five hole sockets (10A), 1 single switch, 1 three hole socket (16A), 2 LED strip lights, complete set of wiring |
Cover |
1.00 |
|
Auxiliary materials |
Auxiliary materials |
Screws, drill tail nails, sealant, internal box connectors |
Cover |
1.00 |
Advantages and features of crate modular houses
Lightweight and high-strength materials are used to reduce the overall weight
Waterproof, moisture-proof and fireproof options: Waterproof, moisture-proof and fireproof materials are selected to ensure that the house can maintain good performance in various environments.
A variety of size and layout options are available to meet the needs of different users. Design expandable or retractable components so that the house can be expanded or reduced as needed.
Application
1. It can be applied to offices, residences, and dormitories. It is simple to build and simple and generous
Specifications: Specifications of products on sale 6055*2990*2896 can be customized
Contact
Welcome to purchase high-end crate modular houses. It is inexpensive and easy to install.
