Introduction
Our company started to deal with containers decades ago, and now has a history of 20 years. We have rich experience in container housing and have obtained international ISO9001 and CE certification.
Container housing is specially designed for convenient housing. It is quick to install and can be moved in within a few days. It is formaldehyde-free. We use environmentally friendly insulation materials. The main frame is steel. After the main structure, pipelines and some interior decoration are completed in the factory, they are transported to the site and combined into a complete building through high-strength connection technology (bolts, welding or plug-in). This technology combines industrialized manufacturing with flexible design and is widely used in multi-story buildings, public facilities and special scenes.
Details
Jiangsu Suqian Longze Modular Building Co., Ltd. is a professional enterprise in the field of integrated housing integrating scientific research, production, installation and service, mainly engaged in wholesale and retail. It can produce 100 fast-assembly boxes, 30 packing boxes, 45 fixed boxes and 3,000 meters of sandwich panels per day.
Product Description
Stable Structure
Container home shipping container are built with steel structures, which are stable and reliable.
Exquisite Workmanship
The packaging house is equipped with steel soundproof doors and metal lock cylinders, which is high-end and elegant.
Anti-theft function
The windows are made of excellent plastic steel, and anti-theft nets are also added around them, which not only makes ventilation and airflow more comfortable, but also prevents theft and is very safe.
Specification parameters
|
Technical specifications requirements for packaging boxes |
||||
|
Component name (customizable) 6055 * 2990 * 2896mm |
This configuration is a standard model |
Unit |
Quantity |
|
|
Main frame 2.3mm |
Top frame |
Electrostatic baking paint top crossbeam 170mm |
Branch |
2.00 |
|
Electrostatic baking paint top side beam 170mm |
Branch |
2.00 |
||
|
40 * 60 1.3mm square tube |
Branch |
5.00 |
||
|
20 * 40 * mm square tube, 20 * 20 * mm square tube |
Branch |
3.00 |
||
|
Bottom frame |
Electrostatic baking paint bottom crossbeam 160mm |
Branch |
2.00 |
|
|
Electrostatic baking paint bottom side beam 160mm |
Branch |
2.00 |
||
|
Square tube 50 * 100 cross brace |
Branch |
9.00 |
||
|
Integrated floodwater tank |
Cover |
1.00 |
||
|
Column |
Complete set of painted columns, 150 * 210mm |
Branch |
4.00 |
|
|
Corner piece |
Painted corner piece 160 * 160 * 200mm |
Individual |
4.00 |
|
|
Painted corner piece 160 * 160 * 160mm |
Individual |
4.00 |
||
|
Color roll cap |
0.46mm color steel coil, pressed into a special 980 watt shape, with higher strength, no deformation, no water retention, 360 degree bite, special waterproof method |
Cover |
1.00 |
|
|
Top insulation |
50mm insulation glass wool, melting weight 18kg/m ³, PE resin moisture-proof film |
Cover |
1.00 |
|
|
Downpipe |
Downpipe |
50 # PVC downpipe |
Branch |
4.00 |
|
Suspended ceiling |
Complete ceiling |
2820 * 831 * 0.3mm color steel integrated ceiling panel with patterned pattern, with angled aluminum |
Cover |
1.00 |
|
Door |
Steel Security Doors |
Luxury steel integrated door for packaging box 840 * 2035 |
Individual |
1.00 |
|
Window |
Security window |
Double glass hollow plastic steel window 925 * 1100mm, equipped with anti-theft and screen windows as standard |
Individual |
2.00 |
|
Wallboard |
Composite plate |
950 * 50mm rock wool composite board, double-sided 0.3 steel plate, rock wool melting weight 70kg/m ³ |
Cover |
1.00 |
|
Ground |
Cement pressure fiberboard |
2830*1174*18mm |
Cover |
1.00 |
|
Floor leather |
1.6mm, Floor leather |
Cover |
1.00 |
|
|
Baseboard |
PVC material |
Cover |
1.00 |
|
|
Inside corner |
Concave line |
Color steel inner corner line, white gray |
Branch |
4.00 |
|
Electric distribution |
Electric distribution |
Industrial socket box, 1 set of industrial sockets, 1 distribution box, 1 air switch (32A), 3 five hole sockets (10A), 1 single switch, 1 three hole socket (16A), 2 LED strip lights, complete set of wiring |
Cover |
1.00 |
|
Auxiliary materials |
Auxiliary materials |
Screws, drill tail nails, sealant, internal box connectors |
Cover |
1.00 |
Advantages and features of spliced steel structure modules
Convenient transportation: Modular design supports overall or split transportation,
Detachable migration: The house can be quickly disassembled and reassembled to meet temporary housing needs or site change requirements.
Reduce pollution: Factory prefabrication reduces on-site construction waste, dust and noise pollution.
Energy-saving design: The wall integrates thermal insulation layer to reduce daily energy consumption
Application
1. It can be used for office, residence, and dormitory, with simple construction, simple and generous
Specifications: Specifications of products on sale
6055*2990*2896 can be customized
