Name: China Customized Portable Prefab Tiny Homes Manufacturers Suppliers Factory - Good Price - Longze
Brand: Longze
SKU: 269676320

Description

Technical Parameters

Factory Scale
Covers an area of more than 30 acres, with a factory area of 15,000 square meters

Production Capacity
3 sandwich panel production lines (EPS/ polyurethane/ rock wool/ glass wool sandwich panels)
1 fully automatic electrostatic coating line
5 automatic welding production lines
7 color profiled tile production lines (800 glazed tiles, 831 ceiling tiles and other specifications)
6 steel profile forming production lines

Daily Production Capacity
200 containers of various types
5,000 meters of color steel sandwich panels

Product Application Areas

Large industrial plants, electronic clean workshops
Warehouses, cold storage, mobile homes
Building floors, clean workshops
Various places that require insulation

International Market
In recent years, products have been exported to many countries, with annual sales of 6 million US dollars.

Corporate Values
Longze Module combines 20 years of container manufacturing experience with modular building technology to provide global buyers with one-stop modular building solutions from design, manufacturing to delivery, and continue to promote innovation and development in the prefabricated building industry.

Installation process: Quick installation, completed in 2 hours, simple and fast

Internal Space

Various Engineering Cases

Specification parameters

20 feet	External dimensions (mm)	590063202480
	Folded state (mm)	590022002480
	Total mass (kg)	2900
40feet	External dimensions (mm)	1180063202480
	Folded state (mm)	1180022002480
	Total mass (kg)	4700
Other size	Customized on request
Frame Structure	Steel structure	Q235 galvanized steel frame
	Middle roof beam	Q235 galvanized steel frame (2.5-3mm)
	Middle base beam	Q235 galvanized steel frame (2.5-3mm)
	Side beam	Q235 galvanized steel frame (1.5-2mm)
	Side wall frame	Q235 galvanized steel frame (1.5-2mm)
	Middle PILLIAR	Q235 galvanized steel frame (2.5-3mm)
	Subframe	Q235 galvanized steel frame (1.5-2mm)
	Protective coating of the whole frame	Electrostatic spraying/white plastic powder spraying
Top	External roof panel	Fire retardant EPS insulation sandwich panel and roof corrugated veneer
Top	Internal CELLING panel	0.25 type-200 CELLING
Wall	Mid-roof insulation	50mm fire retardant insulation sandwich panel/color steel panel with glass filament wool
	Side wall, front wall panel and rear wall panel	65mm fire retardant insulation sandwich panel/color steel panel with glass filament wool
	Internal partition	55m environmentally friendly insulation material
Floor	Middle floor	18mm fire retardant glass magnesium board/fire retardant cement fiber floor
Floor	Both sides floor	18mm bamboo floor/thick bamboo plywood
Electrical System (Customized)	Electrical wiring, installation strictly in accordance with moisture-proof specifications, all electrical products should comply with certification. Connect the circuit according to the circuit engineering specifications, indoor: 2 LED lights, 2 CEILIING lights, 3 five-hole single sockets, 1 single switch, 3 ten-hole sockets, 1 air-conditioning socket, 1 20a-leakage protector. Voltage 220V, 50hz
Electrical System (Customized)	We can customize circuits that meet certification requirements according to different countries.
Door	Broken bridge aluminum entrance door (with password lock), bedroom metal swing door
Windows	Aluminum alloy windows, double-layer heat-insulating tempered glass

Packaging And Shipping

Advantages of portable prefabricated small houses
1. Portable prefabricated small houses are extremely safe against earthquakes, strong winds and sound insulation.
2. With bathroom shower, dry and wet separation.
3. High-quality security door. Small footprint, really easy to install
4. Different types of interior rooms, waterproof wooden floors, more comfortable.
5. Good appearance and design as customer requirements;

Application
1. Can be applied to office, residence, as dormitory

Contact
Welcome to buy high-end module containers. It is inexpensive and easy to install.
Email: Lzmk88888888@163.com

FAQ

Q: Is your price more competitive than other companies?

A: Our business goal is to provide each customer with the best price of the same quality and the best quality of the same price. We abide by the creed that helping customers is helping ourselves, and we try our best to meet the requirements of every friend.

Q: Do you provide installation services?

A: We provide detailed installation drawings and videos for free. If necessary, we can send engineers or instructors to the construction site, especially for large projects.

Q: How long can a new prefab house last?

A: That's a good question. With its mobile properties, it can be folded over 100 times. With proper care and maintenance, a new prefab house can last as long as a standard building.

Q: Is the structure of the block house painted with anti-rust paint?

A: Don't worry. The folding house is waterproof, windproof and fireproof, and can withstand cold weather.

Q: Which countries do you export this module house product to?

A: We have shipped the house to more than 100 countries. Like the United States, Canada, Australia, New Zealand, Peru, Brazil, Malaysia, Philippines, India, etc.
